        Noritz® GQ-C3260WX-FF US LP
        Send Print
        1. pin-int
        Noritz® GQ-C3260WX-FF US LP

        Noritz® EZ Series GQ-C3260WX-FF US LP Condensing Water Heater, 0.83 gal, 180

        Noritz® GQ-C3260WX-FF US LP

        Engineered expressly for the north American residential market, the EZ series of high-efficiency, condensing tankless water heaters from Noritz® America are designed to cut installation time and cost when replacing larger, storage tank type units. The ENERGY STAR® rated EZ98-DV and EZ111-DV join the previously released EZTR40 to provide professional installers and their homeowner customers with a wider range of tankless options, covering the majority of residential, tank replacement opportunities.

        Noritz® Condensing Water Heater, EZ Series, 0.83 gal Capacity, 18000 to 199900 Btu/hr, 80 W, 0.5 to 11.1 gpm Flow Rate, 0.97 Energy Factor, 2 in, 3 in Vent, Direct Vent, 4 A, 120 V, 60 Hz, NPT Connection, 15 to 150 psi, Energy Star Compliant: Yes, Wall Mounting, Propane Gas Fuel, Direct Electronic Ignition System, Stainless Steel, Finish: Polyester-Coated, Contains Lead, 100 to 140 deg F, 27 in H x 18.5 in W x 14.1 in D

        Series      :      EZ Series
        Capacity      :      0.83 gal
        BTU Rating      :      18000 to 199900 Btu/hr
        Power Rating      :      80 W
        Flow Rate      :      0.5 to 11.1 gpm
        Energy Factor      :      0.97
        Vent Size      :      2 in, 3 in
        Vent Type      :      Direct
        Amperage Rating      :      4 A
        Voltage Rating      :      120 V
        Frequency Rating      :      60 Hz
        Connection Type      :      NPT
        Pressure Rating      :      15 to 150 psi
        Energy Star Compliant      :      Yes
        Mounting Type      :      Wall
        Fuel Type      :      Propane Gas
        Ignition System      :      Direct Electronic
        Material      :      Stainless Steel
        Finish      :      Polyester-Coated
        Lead-Free/Contains Lead      :      Contains Lead
        Temperature Rating      :      100 to 140 deg F
        Dimensions      :      27 in H x 18.5 in W x 14.1 in D
        • Both new EZ model have their hot and cold water connections located on top of the unit not the bottom, like most tankless heaters
        • This positioning allows the flexible water lines used by the previous tank heater to be quickly and easily reconnected to the new unit
        • The Noritz® connect app is compatible with both of the new units, allowing for wireless remote control of heater functions, as well as diagnostic and maintenance reminders
        • Inside each EZ model are two stainless steel heat exchangers that have a greater resistance to corrosion and scale build-up than other materials, thereby boosting system life
