Jomar Valve® 105-613G
Jomar Valve® In-Line Check Valve, 1/2 in Nominal, Solder Connection, 300 psi, Pressure Class: 150 lb, 250 deg F, 0.49 in Opening, Brass Body, PTFE Disc, PTFE Trim, PTFE Softgoods, Lead-Free, 2.09 in L x 1.28 in H
| Nominal Size | : | 1/2 in |
| Connection Type | : | Solder |
| Pressure Rating | : | 300 psi |
| Pressure Class | : | 150 lb |
| Temperature Rating | : | 250 deg F |
| Opening Size | : | 0.49 in |
| Body Material | : | Brass |
| Disc Material | : | PTFE |
| Trim Material | : | PTFE |
| Softgoods Material | : | PTFE |
| Lead-Free/Contains Lead | : | Lead-Free |
| Dimensions | : | 2.09 in L x 1.28 in H |
- Dezincification-resistant brass alloy
- Forged lead-free brass body
- Can be installed in vertical or horizontal positions
- Bubble-tight PTFE seal
- Wetted surface contain <0.25% lead content
