        Harris® 9006257

        Harris® 9006257 Flow Gauge, 50 mm Dial, 0 to 30 psi, 1/8 in

        Harris® 9006257

        Harris® Flow Gauge, 50 mm Dial, 0 to 30 psi Measuring, 1/8 in Connection, Male BSP Connection, ABS

        Dial Size      :      50 mm
        Measuring Range      :      0 to 30 psi
        Connection Type      :      Male BSP
        Material      :      ABS
        Color      :      Flat black paint
        Connection Size      :      1/8 in
        Compatible With      :      Regulator Models 601-15-200 A&B, 601-15-520 A&B, 601-50-510P
        Construction      :      ABS case;Polycarbonate clear snap-in lens
        ModelName      :      50MM 30 PSI / 2 BAR Gauge
        Scale Range SCFH      :      0 - 30 PSI / 2 BAR
        Size      :      50mm
        Special Instructions      :      BSP stem gasket required for tight seal - PN 9000643
        • Flat black painted ABS plastic construction is lightweight while durable and corrosion resistant
        • 50mm dial diameter
        • 30 PSI / 2 BAR pressure rating
        • Easy-to-read white steel background with dual scale (PSI/BAR) and dual colored (red/black) dial face
        • Snap-in one-piece polycarbonate clear lens cover
        • Brass G 1/8" BSP threaded lower stem mount
        • Gauge mounting requires a gasket (PN 9000643)
        • One year warranty
