11 EER Energy efficient and built to last, the Single Stage Wall-Mount AC Units offer Balance Climate for maximum indoor comfort at a minimal cost. Designed for a variety of applications, these AC units also provide quiet operation. Factory or field installed accessories are available to meet specific job requirements.
Bard® Air Conditioner, Series: W60A Series, Model: W60AY, 5 ton Nominal Capacity, 57000 Btu/hr Cooling, 57000 Btu/hr Cooling BTU Rating, 230/208 V, 41 A, 1/3 hp Rating, 825 rpm Rotational Speed, 60 Hz, 1 ph, Scroll Compressor, Vertical Configuration, 3100 cfm Rating, 11 EER, 5 Speed, 1 Stage, R-410A, 66.8 dBA, Wall Mount, ECM Motor, 20 x 20 x 1 in Filter, 50 A Fuse, Alarm Relay, Low Ambient Control, Steel, Baked Enamel/Zinc-Coated, Buckeye Gray, 0 to -40 deg F, 93 in H x 42 in W x 25.5 in D, Additional Information: Standard Fresh Air Damper Vent Package, 2 in MERV8 Disposable Filter, Standard Copper/Aluminum Coils, Standard Supply Outlet
| Series | : | W60A Series |
| Model | : | W60AY |
| Cooling BTU Rating | : | 57000 Btu/hr |
| Nominal Capacity | : | 5 ton |
| Voltage Rating | : | 230/208 V |
| Amperage Rating | : | 41 A |
| Refrigerant Type | : | R-410A |
| Mounting Type | : | Wall |
| HP Rating | : | 1/3 hp |
| Cooling Capacity | : | 57000 Btu/hr |
| Rotational Speed | : | 825 rpm |
| Frequency Rating | : | 60 Hz |
| Phase | : | 1 ph |
| Compressor Type | : | Scroll |
| CFM Rating | : | 3100 cfm |
| Configuration | : | Vertical |
| Sound Level | : | 66.8 dBA |
| EER Rating | : | 11 |
| Number of Stages | : | 1 |
| Fuse Rating | : | 50 A |
| Motor Type | : | ECM |
| Temperature Rating | : | 0 to -40 deg F |
| Material | : | Steel |
| Finish | : | Baked Enamel/Zinc-Coated |
| Color | : | Buckeye Gray |
| Dimensions | : | 93 in H x 42 in W x 25.5 in D |
| Additional Information | : | Standard Fresh Air Damper Vent Package, 2 in MERV8 Disposable Filter, Standard Copper/Aluminum Coils, Standard Supply Outlet |
- 11.0 EER cooling efficiency
- 3.5 to 6.0 ton cooling capacity
- Single and three phase power options
- Copeland scroll compressor
- EC brushless constant tourque indoor blower motor
- R-410A green refrigerant
- Balanced Climate
- Natural fiber non-fiberglass insulation
- Hydrophilic aluminum finned copper evaportator coil
- Front access control compartment
- Factory installed electric heat
- Factory installed ventilation options
- AHRI Certified
- ETL Listed (US and Canada)
Specification Sheet
