        Navac NX1V

        Navac NX1V Digital Manifold Gauge, 7/16 in Connection

        Navac NX1V

        The NAVAC NX1V Nexus Digital Manifold Gauge enhances the HVAC diagnostics experience with its wireless features. Bluetooth connectivity for temperature probes and micron gauges provides comprehensive remote insights all on the screen of Nexus. It caters to various needs with 4 operation modes (Manifold, Leak Test, Evacuation, and Decay Test). Built with an aluminum body and a 1/4 turn ball valve, it ensures durability. The foldable hidden hook enhances portability, while its Class 0.4 accuracy and clear digital display offer precise readings. Impact-resistant and covered in durable rubber, the NX1 withstands field challenges, ensuring a prolonged, resilient work experience.

        Navac Digital Manifold Gauge, For Use With: R-11, R-12, R-13, R-22, R-23, R-32, R-113, R-114, R-115, R-116, R-123, R-124, R-125, R134a, R-236fa, R-245fa, R-290, R-401A, R-401B, R-402A, R-402B, R-403B, R-404A, R-406A, R-407A, R-407B, R-407C, R-408A, R-409A, R-410A,R-413A, R-414A, R-414B, R-416A, R-417A, R-417C, R-420A, R-421A, R-421B, R-422A, R-422B, R-422C, R-422D, R-424A, R-427A, R-428A Refrigerant Type, Class 0.4 Accuracy, 7/16 in Connection, -30 inHg to 720 psi, 32 to 104 deg F, UNF Thread End Connection, Aluminum, Additional Information: Rechargeable Li-Ion Battery

        Suitable For Use With      :      R-11, R-12, R-13, R-22, R-23, R-32, R-113, R-114, R-115, R-116, R-123, R-124, R-125, R134a, R-236fa, R-245fa, R-290, R-401A, R-401B, R-402A, R-402B, R-403B, R-404A, R-406A, R-407A, R-407B, R-407C, R-408A, R-409A, R-410A,R-413A, R-414A, R-414B, R-416A, R-417A, R-417C, R-420A, R-421A, R-421B, R-422A, R-422B, R-422C, R-422D, R-424A, R-427A, R-428A Refrigerant Type
        Accuracy      :      Class 0.4
        Connection Size      :      7/16 in
        Pressure Rating      :      -30 inHg to 720 psi
        Temperature Rating      :      32 to 104 deg F
        End Connection      :      UNF Thread
        Material      :      Aluminum
        Additional Information      :      Rechargeable Li-Ion Battery
        • Bluetooth connections with temp clamps and micron gauge (sold separately)
        • Aluminum Body w/ 1/4 Turn Ball Valve - Reliable, efficient and durable, Better work experience
        • Multi-Operation Modes - Manifold mode with SH/SC display, Pressure Test mode, Evacuation mode
        • Folding Hook - Hidden hook design, Easy to transport
        • Digital and Accurate - Class 0.4 accuracy with digital display, Precision at a glance
        • Impact-resistant design
        • Durable rubber cover
